Laser welding machine FPL - 1500 Pro

Description

The Felgenprofessor laser welding machine FPL-1500 Pro, with an output of 1,500 watts, is ideal for the precise welding of aluminum rims. Laser beam welding enables a concentrated energy input into the rim, which ensures precise weld seams and spot welding with minimal thermal distortion.

The temperature applied to the rim is only between 40°C and 50°C, which means perfect results can be achieved in a short time.

This hand-held device uses the latest generation of fiber laser technology and is designed to withstand the highest loads. Integrated water cooling ensures that maximum power is always available. The ergonomically designed laser welding torch enables comfortable handling, even during longer periods of use.

Functions

• The Felgenprofessor laser welding machine FPL-1500 Pro, with an output of 1,500 watts, is ideal for the precise welding of rims.

Features & Benefits

• The desired settings can be quickly selected via the clear touch control panel.
• The device offers a separate synergic welding wire guide with 4-roller drive and overheating protection.
• With a laser class of 4, wearing protective goggles is mandatory. We also recommend additional protective measures such as safety clothing, a protective mask with respiratory filters and the use of laser protection walls. Please comply with all necessary safety regulations.
• The practical hand laser is operated via a 230 volt mains connection.
• The laser welding machine comes with extensive accessories!

Benefit from the FPL-1500 Pro for perfect work results in the shortest possible time – the ideal tool for professional applications in rim repair!

Technical data

• Laser type: fiber laser
• Laser class: 4
• Power: 1,500 W | 1.5 kW
• Mains voltage: 230 V
• Frequency: 50 | 60 Hz
• Wavelength: 1080 nm ± 3 nm
• Cooling: Water cooling
• Wire guide rollers: 0.8 | 1.0 | 1.2 | 1.6 mm
• Length of hose package: 10 m
• Working temperature: 40°C - 50°C
• Dimensions: 980 x 420 x 712 mm
• Weight: 115 kg
• Spool holder: 50 mm mandrel

Shipment

If this product is in stock, it will be shipped within 1-2 days. If it is not available, the delivery time is 8-12 weeks
